UV curing
MULTIline FORCE UV
High-strength hose liner for the structural rehabilitation of pipes.
Liner with a TPU coating built for UV light-train curing — the crew controls exactly when the reline sets, up to DN 600.
- DN 100 – 600
- 3.30 mm wall
- UV cure
Technical data
| Product code | FORCEUV |
|---|---|
| Length | 50 m; 100 m / 164 ft; 328 ft |
| Diameter | 100 mm – 600 mm / 4 inch – 24 inch |
| Wall thickness | 3.30 mm / 0.13 inch |
| Liner undersized | 10 % |
| Heat resistance | Max. 80 °C / 176 °F |
| Negotiating bends | Max. 45° |
| Material | Needle-punched fleece with thermoplastic polyurethane (TPU) coating |
| Textile | Polyester, 500 g/m² |
| Coating | TPU, 150 g/m² |
| Colour / coating | White / Transparent |
| Storage | Protected from light, dry |
Always confirm against the current data sheet before use.
Need this for a project?
Tell us the diameter, length and application and our technical team will confirm the right liner and resin combination.
